The LM324DR2G is a quad Operational Amplifier with true differential inputs. It has several distinct advantages over standard operational amplifier types in single supply applications. The quad amplifier can operate at supply voltages as low as 3V or as high as 32V with quiescent currents about one-fifth of those associated with the MC1741 (on a per amplifier basis). The common-mode input range includes the negative supply, thereby eliminating the necessity for external biasing components in many applications. The output voltage range also includes the negative power supply voltage.
The ONSEMI LM324DR2G operational amplifier is designed for efficient performance in various applications, particularly in the automotive sector. With its quad configuration, it provides flexibility in design while maintaining low power consumption.
As an import-on-demand sourced component, we ensure timely delivery across India, typically within 12-15 working days. Our procurement model supports INR billing and GST invoice, making it seamless for your purchasing needs.
| Key | Description |
| IC Case / Package | SOIC |
| Input Bias Current | -90 nA |
| Supply Voltage Range | 3V to 32V |
| Operating Temperature Min | 0 °C |
| No. of Pins | 14 Pins |
| Amplifier Type | Low Input Bias |
| MSL | MSL 1 - Unlimited |
| IC Mounting | Surface Mount |
| Gain Bandwidth Product | 1 MHz |
| Input Offset Voltage | 2 mV |
| Slew Rate Typ | 0.6 V/µs |
| No. of Channels | 4 Channels |
| Operating Temperature Max | 70 °C |
| Parameter | Value |
| Product Name | LM324DR2G - Operational Amplifier, Quad, 4 Channels, 1 MHz, 0.6 V/µs, 3V to 32V, SOIC, 14 Pins |
| Manufacturer / Brand | ONSEMI |
| MPN | LM324DR2G |
| RoHS | YES |
| Country of Origin | CN |
| Hazardous | false |
